- Double manually doors
- Keyswitch
- Powder coated RAL- 7004
- Lyfting height 500 – 1000mm
- No pit required
- CE-marked, type certified by Inspecta fulltills SS-2097-7
- Simple attachment against a wall - ceiling the lifting device heeds a steady ground
- Can be mounted on a free standing frame
- Safety plate under the platform
- Emergency lowering by a crank or UPS
- Side panels and doors have polycarbonate a safety protection
Technical description:
- Single phase, 1 x 230V, 16A
- Rated load: 300kg or 2 persons
- Lifting height: 0,5 – 3,0m
- Speed: 0,08 m/s
- Motor: 2,5Kw, beltdrive, double screw and nut
- Electrical connection: 3 x 2,5 mm²
- Manouver: 24 Volt
- Soft start / stop with frequency inverter
